Flexible bending machine center 2500 shipped to South African customers
Flexible bending machine center solves various complex sheet metal bending problems in metal forming
The center of flexible bending machine focuses on solving various complex sheet metal and bending problems in metal forming. Through multi-axis concurrent linkage, sheet metal operations are automatically completed, and the dependence on molds and labor is solved from a technical point of view, effectively improving production efficiency and reducing production costs.
Easily realize the bending requirements of circular arc, dead edge, return type, closed type and other complex types of sheet metal.
The flexible bending machine center can be widely used in the field of steel cabinet shells (file cabinets, tool cabinets, outer shields, electrical cabinets, communication cabinets, gas cabinets, water meter cabinets…), kitchen utensils (refrigerators, air conditioners, cookers… ), furniture, ventilation, refrigeration, purification, door industry, decoration, elevator and other related metal forming fields.
The whole machine is designed and produced according to the standard of high-precision machine tools. The main bed is made of high-grade castings, and the castings and welded parts are treated with strict stress relief process. Long-term running accuracy, stability and high rigidity.
High-grade castings
The core frame of the equipment adopts high-grade QT500-7 and HT250 castings, and the castings are measured by testing instruments. After accurate finite element force analysis, the frame adopts stable triangular interconnection design, which greatly ensures the stability under high tonnage impact force.
High standard welding
Carbon dioxide shielded welding is used in the whole welding process, and the welding place adopts the full welding process to ensure that the welded workpiece is firm and beautiful.
Stress relief treatment
The supporting table for castings and welding adopts a high-precision temperature-controlled furnace, and performs multiple tempering, annealing and other heat treatment processes according to the temperature curve corresponding to the material, and then performs a long-term full-frequency vibration aging treatment to release the internal stress of the workpiece, and it will not be used for a long time. deformed.
Precision machining
Different fixtures are designed for different workpieces, and high-precision multi-axis machining centers are used to finish the workpieces to ensure the consistency of precision before and after clamping.
Strict testing
Adopt high-precision micrometer U meter, cooperate with marble platform and marble square ruler with long service life, carry out precise measurement for each workpiece, strictly control the processing quality of each workpiece, and check layer by layer, so that the assembly accuracy of the whole machine conforms to high-precision Machine tool standard.
Domestic flexible bending machine to see PM2500
The domestic flexible bending machine PM2500 is a high-level servo flexible bending center developed by Primapress intelligent equipment technology research and development department after 2 years of technical research. The bending speed is only 0.2 seconds per knife, and the equipment can be automatically folded according to the bending process. , The lower folding action realizes the combined bending of arc, dead edge and various angles, and can achieve various bending requirements without changing the bending tool, saving a lot of labor and mold costs for the enterprise.
The maximum processing plate size is 2500mmx1500mm, control X, Y, C, V1, V2, Z1, Z2, W1, W2, P a total of 10 axes. The feature of the domestic flexible bending machine PM2500 is that it adopts a C-shaped pressing arm structure, and the end adopts a crank connecting rod mechanism to drive the presser foot to press down, press the plate, and realize the feeding method of moving and rotating the plate.
The parameters of the domestic flexible bending machine PM2500 are introduced as follows:
The use of PM2500 for domestic flexible bending machines: It can be widely used in the field of steel cabinet shells (file cabinets, tool cabinets, outer shields, electrical cabinets, communication cabinets, gas cabinets, water meter cabinets…), kitchen utensils (refrigerators, Air conditioners, stoves…), furniture, ventilation, refrigeration, purification, door industry, decoration, elevators and other related metal forming fields.
