1000W 1500W 2000W 3000W 4000W 6000w Sheet metal CNC fiber laser cutting machine with Full Cover
Graphic Format Supported:AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
CNC or Not:Yes
Cooling Mode:Water Cooling
Place of Origin:Anhui, China (Mainland)
Model Number:fiber laser cutting machine
Item:metal fiber laser cutting machine
color:as your need
laser tube:150w 180w 280w 300w
Laser type:fiber laser
Power supply:220V±10% /50Hz , 110V±10%
Graphic format supported:BMP, PLT,DST,DXF,AI,CDR
Software supported:CorelDraw, PhotoShop
Highest Scanning Precision:2000DPI
After-sales Service Provided:Engineers available to service machinery overseas
|Item / Model||ECO-FIBER-1530|
|Cutting area||1300 x2500mm|
|Laser type||fiber laser|
|Focus Method||Dynamic Following and Automatic Adjust Focus|
|Resetting positioning accuracy||≤±0.01mm|
|Power supply||380V/50HZ (Optional 220V/50HZ)|
|Operating temperature||0 – 45°C|
|Operating humidity||5 – 95%|
|Min. shaping character||English 1.0 x 1.0mm|
|Graphic format supported||BMP, PLT, DST, DXF, AI|
|Software supported||TAJIMA, CorelDraw, Photoshop, AutoCAD|
|Driving system||Japanese Panasonic Servo motor & Driver|
|Cooling mode||Water-cooling and protection system|
|Shipping Dimensions||2090 x 1500 x 1570mm|
|Optional Spare Parts||Up-down clump, Rotary System, Honeycomb table|
|Control Method||offline movement Control|
carbon fiber laser cutting machine features:
1. Advanced Germany Technology: ensure most high tech in the world.
2. Advanced Laser Optical System: Ensure Excellent Laser Beam Quality Double-Xenon-lamp technology, can strongly improve the laser power and laser beam quality.
3. Laser Path Pre-view & Pre-position Function: Laser beam is in-visible by adopting “Red Light Pointer”,Realize the laser path pre-view and Pre-position function.
4. Pre-view and pre-run function: Simulate the laser cutting path, Pre-run the cutting path in advance, Ensure finding the accurate cutting position.
5. Unique Mirrors and Lens Cooling Technology: All mirrors and lens is cooled by water, Takes the mirror heat during working, Prolong its’ lifetime, Save future operation cost.
6. Heavy Machine Body: Adopt 100mm*100mm*6mm thick, square metal tube Stable, Heavy Loading, Won’t distortion after long-time using, Worktable Max. Load can reach 500 kgs. Adopt a funnel-type machine bed design, Work with conveyor belt, Easy for user to get the cutting pieces from the machine front.
7. Auto transfer system: Can automatically transfer the cutted work-pieces into the front of machine, Improve working efficiency, Save labor energy, No need user to take it by hand. Make the work-pieces neat and beautiful.
8. Auto Oil-filling system: Press for once, can lubricate the machine transmission rod for 2-3 months.
9. Red light pointer: As the laser beam is in-visible, We adopt red light pointer to indicate the real position ofthe laser beam, Make cutting more accurate.
10. Dynamic Auto-focus System: Keep the same distance between the metal sheet and laser head, Realize the accuracy of cutting effect.
11. Auto-feeding Design: Adopt feeding wheel design, Make the material feeding easier, Labor energy saving.
